Methodology

COOLCITY Indicators

Source data and thematic maps

The COOLCITY Index is based on satellite data from the Sentinel-2 (ESA) and Landsat-8 and Landsat-9 (NASA) missions. These provide consistent and high-resolution information on the Earth’s surface across the European Union. Their use enables regular and comparable monitoring of changes in the urban environment. The data are processed and transformed into thematic maps.

The thematic map set developed within the COOLCITY Index includes: land cover map, vegetation condition, land surface temperature, and surface radiative properties. Together, these form a consistent dataset describing the condition of urban environments. Environmental indicators are then calculated based on these maps.

COOLCITY Indicators

Based on the maps, we calculated 15 environmental indicators for each urban area. The next step was to derive adaptation challenge indexes. These describe the condition of the urban environment in terms of five key natural aspects: surface permeability, vegetation state, biodiversity, water conditions, and thermal conditions. The indicators were grouped thematically into adaptation challenges and combined using a weighted average.
Finally, the COOLCITY Index value was calculated as the average of the five adaptation challenge indexes. The CCI is a synthetic indicator of cities’ adaptation potential, used to assess the state of blue-green infrastructure in urban areas.
Adaptive challenge COOLCITY Index

Surface permeability

Share of sealed surfaces
Percentage of sealed surfaces in the city.
Land cover map
Biologically active area
Percentage of biologically active area in the city.

Vegetation state

Vegetation cover
Percentage of vegetation cover in the city’s land area.
Land cover map
High vegetation cover
Percentage of high vegetation cover in the city’s land area.
Share of high-vigour vegetation
Percentage of high vigour vegetation (excluding arable land).
Vegetation vigour map Land cover map

Biodiversity

Ecological connectivity
The degree of connectivity between vegetation patches within a city. It describes the continuity and accessibility of green areas throughout the urban environment.
Land cover map
Vegetation diversity
The degree of diversity of vegetation types, calculated based on the area and share of individual vegetation classes. The indicator takes values ranging from 0 to 1.
Vegetation richness
The average number of vegetation classes within a reference unit. The indicator takes values ranging from 0 to 6.
High Biodiversity
Percentage of areas with potentially high biodiversity within the city.

Water Conditions

Surface retention capacity
Potential water retention capacity of the area, expressed as a percentage and estimated based on land cover classes.
Land cover map
Share of wetland ecosystems
Percentage of water and wetland areas in the city.

Thermal conditions

Surface thermal properties
An indicator describing the radiative properties of the land surface in relation to solar radiation. It takes values ranging from −1 to 0. Higher values indicate favorable surface characteristics (a high proportion of dense vegetation and low albedo), whereas lower values indicate unfavorable surface characteristics (absence of vegetation or reduced vegetation health, and high albedo).
Surface temperature
City surface temperature expressed in °C.
Ground thermal properties map
Share of high-temperature areas
Percentage of high-temperature areas in the city.
Surface temperature map
Share of low-temperature areas
Percentage of low-temperature areas in the city.

COOLCITY City Boundaries

COOLCITY City Boundaries

There is no universal definition of a city in the European Union. Therefore, in COOLCITY, a city is defined as an urbanized area managed by a single administrative authority. To define city areas, we use three input datasets:

  • administrative division LAU (Local Administrative Units),
  • degree of urbanization DEGURBA, which considers population size, density, and built-up area density,
  • a point layer of cities enriched with demographic attributes from Eurostat and local statistical offices.

Based on these data, urbanized areas are identified according to the following criteria:

  • population of at least 5,000 residents (based on local statistical offices),
  • urban area of at least 2 km² (except for cities located within metropolitan areas, where this criterion is not mandatory).

Ultimately, 11,041 urbanized areas in the European Union meet these criteria.


Performance Index

Performance Index

The Performance Index is an additional indicator used to assess the extent to which cities effectively utilise their resources and develop high-quality blue-green infrastructure (BGI). It shows the difference between the COOLCITY Index value for a given city and the average value observed in other cities with similar socio-geographical conditions. It reflects the magnitude of benefits achieved through the implementation of blue-green infrastructure in urban adaptation relative to local conditions and opportunities.

The Performance Index models the influence of socio-geographical conditions on a city’s adaptation potential and allows for assessing how much the state of BGI in a given city differs from that of cities developing under similar geographic conditions and levels of urbanisation. This makes it possible to evaluate not only which cities have high adaptation potential, but also which ones make better use of their resources than would be expected given their conditions. A positive value of the index indicates a better-than-expected result, while a negative value may indicate untapped potential.


Quote us

Platform

MGGP AERO. COOLCITY Index 2026

Research article (preprint)

Kopeć D., Tarkowska A., Wietecha M. et al.

The COOLCITY Index: Climate Adaptation Potential Assessment of Blue-Green Infrastructure in 11,041 European Union Cities Using Remote Sensing,

16 June 2026, PREPRINT (Version 1) available at Research Square

https://doi.org/10.21203/rs.3.rs-9817347/v1

Data base

Kopeć, D., Takmadżan, A., Jedliński, J., Żmuda, D., Tarkowska, A., Migas, R., Wietecha, M., Łochowski, M., & Sławik, Ł. (2026).

The COOLCITY Index 2026 for 11,041 cities in European Union

COOLCITY Index 2026 data are available under the CC BY-NC-SA license:

https://doi.org/10.5281/zenodo.20638922

Used data sources

  • Köppen–Geiger climate maps
  • Dynamic World: Near real-time global 10 m land use land cover mapping
  • Copernicus DEM GLO-30 - Global Digital Elevation Model
  • Sentinel-2: ESA’s optical high-resolution mission for GMES operational services
  • Landsat 8–9 Operational Land Imager / Thermal Infrared Sensor Level-2, Collection 2
  • Sentinel-2 MSI: MultiSpectral Instrument, Level-2A
  • NUTS 2021 administrative boundaries
  • Google Earth Engine
  • IPCC Atlas
  • Precipitation ERA5
  • GPM IMERG Final Precipitation
  • Coastal Flooding Hazard
  • HydroRIVERS
  • HydroLakes
  • CloudScore+
